Asus P8P67 Uživatelský manuál

MotherboardP8P67

xP8P67 specications summary(continued on the next page)CPU LGA1155 socket for Intel® 2nd Generation Core™ i7 / Core™ i5 / Core™ i3 Processors Sup

3-34 Chapter 3: BIOS setupChapter 33.10.2 ASUS EZ Flash UtilityThe ASUS EZ Flash Utlity feature allows you to update the BIOS without having to use a

ASUS P8P67 3-35Chapter 33.10.3 ASUS CrashFree BIOS 3 utilityThe ASUS CrashFree BIOS 3 utility is an auto recovery tool that allows you to restore the

3-36 Chapter 3: BIOS setupChapter 3Booting the system in DOS environment1. Insert the USB ash drive with the latest BIOS le and BIOS Updater to the

ASUS P8P67 3-37Chapter 32. The BIOS Updater backup screen appears indicating the BIOS backup process. When BIOS backup is done, press any key to retu

3-38 Chapter 3: BIOS setupChapter 34. Select Yes and press <Enter>. When BIOS update is done, press <ESC> to exit BIOS Updater. Restart y

ASUS P8P67 4-1Chapter 4If Autorun is NOT enabled in your computer, browse the contents of the support DVD to locate the le ASSETUP.EXE from the BIN f

4-2 Chapter 4: Software supportChapter 44.2.2 Obtaining the software manualsThe software manuals are included in the support DVD. Follow the instruct

ASUS P8P67 4-3Chapter 44.3 Software informationMost of the applications in the support DVD have wizards that will conveniently guide you through the

4-4 Chapter 4: Software supportChapter 44.3.2 DIGI+ VRMASUS DIGI+ VRM allows you to adjust VRM voltage and frequency modulation to enhance reliabilit

ASUS P8P67 4-5Chapter 44.3.3 BT GO!BT GO! connects a bluetooth (BT) device with the motherboard through Bluetooth connection for le transferring, l

xi(continued on the next page)P8P67 specications summaryAudio Realtek® ALC892 8-channel High Denition Audio CODEC - BD Audio Layer Content Protecti

4-6 Chapter 4: Software supportChapter 44.3.4 TurboV EVOASUS TurboV EVO introduces TurboV that allows you to manually adjust the CPU frequency and re

ASUS P8P67 4-7Chapter 4Using Advanced ModeClick More Settings, and then click the Advanced Mode tab to adjust the advanced voltage settings.Advanced m

4-8 Chapter 4: Software supportChapter 4CPU RatioAllows you to manually adjust the CPU ratio.The rst time you use CPU Ratio, go to AI Tweaker > CP

ASUS P8P67 4-9Chapter 4Auto TuningASUS TurboV EVO includes two auto tuning modes, providing the most exible auto-tuning options.• The overclocking r

4-10 Chapter 4: Software supportChapter 43. TurboV automatically overclocks the CPU and memory and restarts the system. After re-entering Windows, a

ASUS P8P67 4-11Chapter 44.3.5 EPUEPU is an energy-efcient tool that satises different computing needs. This utility provides several modes that you

4-12 Chapter 4: Software supportChapter 44.3.6 FAN XpertFan Xpert intelligently allows you to adjust both the CPU and chassis fan speeds according to

ASUS P8P67 4-13Chapter 44.3.7 Probe IIProbe II is a utility that monitors the computer’s vital components, and detects and alerts you of any problem

4-14 Chapter 4: Software supportChapter 44.3.8 Sensor RecorderSensor Recorder allows you to monitor the changes in the system voltage, temperature, a

ASUS P8P67 4-15Chapter 44.3.9 MonitorThe Monitor section includes the Sensor and CPU Frequency panels.SensorThe Sensor panel displays the current val

xiiP8P67 specications summaryASUS exclusive overclocking featuresPrecision Tweaker 2: - vCore: Adjustable CPU voltage at 0.005V increment - vCC

4-16 Chapter 4: Software supportChapter 44.3.10 System InformationThe System Information section displays the information about the motherboard, CPU,

ASUS P8P67 4-17Chapter 44.3.11 Audio congurationsThe Realtek® audio CODEC provides 8-channel audio capability to deliver the ultimate audio experien

4-18 Chapter 4: Software supportChapter 44.4 RAID congurationsThe motherboard supports the following SATA RAID solution: Intel® Rapid Storage Techno

ASUS P8P67 4-19Chapter 44.4.2 Installing Serial ATA hard disksThe motherboard supports Serial ATA hard disk drives. For optimal performance, install

4-20 Chapter 4: Software supportChapter 4Creating a RAID setTo create a RAID set:1. From the utility main menu, select 1. Create RAID Volume and pres

ASUS P8P67 4-21Chapter 45. Use the up/down arrow key to select a drive, and then press <Space> to select. A small triangle marks the selected d

4-22 Chapter 4: Software supportChapter 4Deleting a RAID setTake caution when deleting a RAID set. You will lose all data on the hard disk drives when

ASUS P8P67 4-23Chapter 44.5 Creating a RAID driver diskA oppy disk with the RAID driver is required when installing a Windows® operating system on a

4-24 Chapter 4: Software supportChapter 44.5.3 Installing the RAID driver during Windows® OS installationTo install the RAID driver in Windows® XP:1.

ASUS P8P67 4-25Chapter 44.5.4 Using a USB oppy disk driveDue to OS limitation, Windows® XP may not recognize the USB oppy disk drive when you insta

ASUS P8P67 1-1Chapter 11.1 Welcome!Thank you for buying an ASUS® P8P67 motherboard!The motherboard delivers a host of new features and latest technol

4-26 Chapter 4: Software supportChapter 48. Find the [HardwareIds.scsi.iaAHCI_DesktopWorkstationServer] and [HardwareIds.scsi.iaStor_DesktopWorkstati

ASUS P8P67 5-1Chapter 5Chapter 5: ATI® CrossFireX™ technology support5.1 ATI® CrossFireX™ technologyThe motherboard supports the ATI® CrossFireX™ te

5-2 Chapter 5: ATI® CrossFireX™ technology supportChapter 55.2 Installing CrossFireX™ graphics cardsThe following pictures are for reference only. Th

ASUS P8P67 5-3Chapter 55.3 Software information5.3.1 Installing the device driversRefer to the documentation that came with your graphics card packa

5-4 Chapter 5: ATI® CrossFireX™ technology supportChapter 5Enabling Dual CrossFireX settings1. In the Catalyst Control Center window, click Graphics

ASUS contact informationASUSTeK COMPUTER INC.Address 15 Li-Te Road, Peitou, Taipei, Taiwan 11259Telephone +886-2-2894-3447Fax +886-2-2890-

EC Declaration of Conformity We, the undersigned, Manufacturer: ASUSTek COMPUTER INC. Address, City: No. 150, LI-TE RD., PEITOU, TAIPEI 112, TAIWAN R.

1-2 Chapter 1: Product IntroductionChapter 11.3 Special features1.3.1 Product highlightsLGA1155 socket for Intel® Second Generation Core™ i7 / Core™

ASUS P8P67 1-3Chapter 11.3.2 Dual Intelligent Processors 2 with DIGI+ VRMThe world’s rst Dual Intelligent Processors from ASUS pioneered the use of

1-4 Chapter 1: Product IntroductionChapter 1MemOK!MemOK! quickly ensures memory boot compatibility. This remarkable memory rescue tool requires a mere

ASUS P8P67 1-5Chapter 1ASUS Q-ConnectorASUS Q-Connector allows you to easily connect or disconnect the chassis front panel cables to the motherboard.

1-6 Chapter 1: Product IntroductionChapter 1

ASUS P8P67 2-12.1 Before you proceedTake note of the following precautions before you install motherboard components or change any motherboard settin

iiE6307Second Edition (V2) January 2011Copyright © 2011 ASUSTeK COMPUTER INC. All Rights Reserved.No part of this manual, including the products and s

2-2 Chapter 2: Hardware informationChapter 2Refer to 2.2.8 Internal Connectors and 2.3.10 Rear panel connection for more information about internal co

ASUS P8P67 2-3Chapter 2Layout contentsConnectors/Jumpers/Slots Page1. CPU, chassis, and power fan connectors (4-pin CPU_FAN, 4-pin CHA_FAN1, 3-pin

2-4 Chapter 2: Hardware informationChapter 22.2.2 Central Processing Unit (CPU)The motherboard comes with a surface mount LGA1155 socket designed for

ASUS P8P67 2-5Chapter 2Recommended memory congurations2.2.3 System memoryThe motherboard comes with four Double Data Rate 3 (DDR3) Dual Inline Memor

2-6 Chapter 2: Hardware informationChapter 2Memory congurationsYou may install 1GB, 2GB and 4GB unbuffered and non-ECC DDR3 DIMMs into the DIMM socke

ASUS P8P67 2-7Chapter 2Vendors Part No. SizeSS/DSChip BrandChip NO.Timing VoltageDIMM socket support (Optional)1 DIMM 2 DIMM 4 DIMMG.SKILL F3-17600CL7

2-8 Chapter 2: Hardware informationChapter 2Vendors Part No. Size SS/DSChip BrandChip NO.Timing VoltageDIMM socket support (Optional)1 DIMM 2 DIMM 4 D

ASUS P8P67 2-9Chapter 2P8P67 Motherboard Qualied Vendors Lists (QVL) DDR3-1600 MHz capability (continued)Vendors Part No. SizeSS/DSChip BrandChip NO

2-10 Chapter 2: Hardware informationChapter 2Vendors Part No. SizeSS/DSChip BrandChip NO. Timing VoltageDIMM socket support (Optional)1 DIMM 2 DIMM 4

ASUS P8P67 2-11Chapter 2Vendors Part No. SizeSS/DSChip Brand Chip NO. Timing VoltageDIMM socket support (Optional)1 DIMM 2 DIMM 4 DIMMG.SKILLF3-10666C

iiiContentsNotices ... viSafety i

2-12 Chapter 2: Hardware informationChapter 2P8P67 Motherboard Qualied Vendors Lists (QVL) DDR3-1066 MHz capabilityVendors Part No. SizeSS/DSChip Br

ASUS P8P67 2-13Chapter 2Side(s): SS - Single-sided DS - Double-sided DIMM support:• 1 DIMM: Supports one (1) module inserted into any slot as Sin

2-14 Chapter 2: Hardware informationChapter 22.2.4 Expansion slotsEnsure to unplug the power cord before adding or removing expansion cards. Failure

ASUS P8P67 2-15Chapter 2IRQ assignments for this motherboardA B C D E F G HPCIEx16_1 shared – – – – – – –PCIEx16_2 shared – – – – – – –PCIEx1_1 – – sh

2-16 Chapter 2: Hardware informationChapter 22.2.5 Onboard switchesOnboard switches allow you to ne-tune performance when working on a bare or open-

ASUS P8P67 2-17Chapter 22. TPU switchTurning this switch to Enable will automatically optimize the system for fast, yet stable clock speeds.For ensur

2-18 Chapter 2: Hardware informationChapter 23. EPU switchTurning this switch to Enable will automatically detect the current PC loadings and intelli

ASUS P8P67 2-19Chapter 22.2.6 Onboard LEDs1. DRAM LEDThe DRAM LED indicates DRAM status during POST (Power-on Self Test). If an error is found , the

2-20 Chapter 2: Hardware informationChapter 23. TPU LEDThe TPU LED lights when the TPU switch is turned to Enable.4. EPU LEDThe EPU LED lights when

ASUS P8P67 2-21Chapter 22.2.7 JumperClear RTC RAM (3-pin CLRTC)This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear t

ivContents2.5 Turning off the computer ... 2-48Chapter 3: BIOS setup3.1 Know

2-22 Chapter 2: Hardware informationChapter 22.2.8 Internal connectors1. Intel® P67 Serial ATA 6.0 Gb/s connectors (7-pin SATA6G_1/2 [gray])These co

ASUS P8P67 2-23Chapter 22. Intel® P67 Serial ATA 3.0 Gb/s connectors (7-pin SATA3G_3–6 [blue])These connectors connect to Serial ATA 3.0 Gb/s hard di

2-24 Chapter 2: Hardware informationChapter 23. Marvell® Serial ATA 6.0 Gb/s connectors (7-pin SATA6G_E1/E2 [navy blue])These connectors connect to S

ASUS P8P67 2-25Chapter 24. USB 3.0 connector (20-1 pin USB3_34)This connector is for the additional USB 3.0 ports, and complies with USB 3.0 specica

2-26 Chapter 2: Hardware informationChapter 26. IEEE 1394a port connector (10-1 pin IE1394_2)This connector is for an IEEE 1394a port. Connect the IE

ASUS P8P67 2-27Chapter 28. CPU, chassis, and power fan connectors (4-pin CPU_FAN; 4-pin CHA_FAN1; 3-pin CHA_FAN2; 3-pin PWR_FAN1)Connect the fan cabl

2-28 Chapter 2: Hardware informationChapter 29. Front panel audio connector (10-1 pin AAFP)This connector is for a chassis-mounted front panel audio

ASUS P8P67 2-29Chapter 2• For a fully congured system, we recommend that you use a power supply unit (PSU) that complies with ATX 12 V Specication

2-30 Chapter 2: Hardware informationChapter 211. Serial port connector (10-1 pin COM1)This connector is for a serial (COM) port. Connect the serial p

ASUS P8P67 2-31Chapter 2• System power LED (2-pin PLED)This 2-pin connector is for the system power LED. Connect the chassis power LED cable to this

v4.3.5 EPU ... 4-114.3.6 FAN Xpert...

2-32 Chapter 2: Hardware informationChapter 22.3 Building your computer system2.3.1 Additional tools and components to build a PC system1 bag of scr

ASUS P8P67 2-33Chapter 2AB1232.3.2 CPU installationThe LGA1156 CPU is incompatible with the LGA1155 socket. DO NOT install a LGA1156 CPU on the LGA11

2-34 Chapter 2: Hardware informationChapter 2CBA564

ASUS P8P67 2-35Chapter 22.3.3 CPU heatsink and fan assembly installationApply the Thermal Interface Material to the CPU heatsink and CPU before you i

2-36 Chapter 2: Hardware informationChapter 2To uninstall the CPU heatsink and fan assembly2ABBA1

ASUS P8P67 2-37Chapter 2123To remove a DIMM2.3.4 DIMM installationBA

2-38 Chapter 2: Hardware informationChapter 22.3.5 Motherboard installation21The diagrams in this section are for reference only. The motherboard lay

ASUS P8P67 2-39Chapter 2DO NOT overtighten the screws! Doing so can damage the motherboard.3

2-40 Chapter 2: Hardware informationChapter 22.3.6 ATX Power connection12OR OR

ASUS P8P67 2-41Chapter 22.3.7 SATA device connectionOR2OR1

viNoticesFederal Communications Commission StatementThis device complies with Part 15 of the FCC Rules. Operation is subject to the following two cond

2-42 Chapter 2: Hardware informationChapter 22.3.8 Front I/O ConnectorIDE_LEDPOWER SWRESET SWIDE_LED-IDE_LED+PWRResetGroundGround1 2USB 2.0AAFPTo ins

ASUS P8P67 2-43Chapter 22.3.9 Expension Card installationTo install PCIe x16 cardsTo install PCIe x1 cards To install PCI cards

2-44 Chapter 2: Hardware informationChapter 22.3.10 Rear panel connectionRear panel connectors1. PS/2 mouse port (green) 7. USB 2.0 ports 5 and 62.

ASUS P8P67 2-45Chapter 22.3.11 Audio I/O connectionsAudio I/O ports ***Audio 2, 4, 6, or 8-channel congurationPort Headset 2-channel4-channel 6-chan

2-46 Chapter 2: Hardware information2-46 Chapter 2: Hardware informationChapter 2Connect to Headphone and MicConnect to Stereo SpeakersConnect to 2.1

ASUS P8P67 2-47ASUS P8P67 2-47Chapter 2Connect to 5.1 channel SpeakersConnect to 7.1 channel SpeakersWhen the DTS Surround Sensation UltraPC function

2-48 Chapter 2: Hardware informationChapter 22.4 Starting up for the rst time1. After making all the connections, replace the system case cover. 2.

ASUS P8P67 3-1Chapter 3Chapter 3: BIOS setupChapter 33.1 Knowing BIOSThe new ASUS EFI BIOS is an Extensible Firmware Interface that complies with uE

3-2 Chapter 3: BIOS setupChapter 33.2.1 EZ ModeBy default, the EZ Mode screen appears when you enter the BIOS setup program. The EZ Mode provides you

ASUS P8P67 3-3Chapter 33.2.2 Advanced ModeThe Advanced Mode provides advanced options for experienced end-users to congure the BIOS settings. The g

viiSafety informationElectrical safety• To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating t

3-4 Chapter 3: BIOS setupChapter 3Menu itemsThe highlighted item on the menu bar displays the specic items for that menu. For example, selecting Main

ASUS P8P67 3-5Chapter 33.3 Main menuThe Main menu screen appears when you enter the Advanced Mode of the BIOS Setup program. The Main menu provides y

3-6 Chapter 3: BIOS setupChapter 3Administrator PasswordIf you have set an administrator password, we recommend that you enter the administrator passw

ASUS P8P67 3-7Chapter 33.4 Ai Tweaker menuThe Ai Tweaker menu items allow you to congure overclocking-related items.Be cautious when changing the se

3-8 Chapter 3: BIOS setupChapter 3Ai Overclock Tuner [Auto]Allows you to select the CPU overclocking options to achieve the desired CPU internal frequ

ASUS P8P67 3-9Chapter 3Changing the values in this menu may cause the system to become unstable! If this happens, revert to the default settings.CPU P

3-10 Chapter 3: BIOS setupChapter 3Long Duration Maintained [Auto]Use the <+> and <-> keys to adjust the value.Short Duration Power Limit

ASUS P8P67 3-11Chapter 3Manual Adjustment [Medium]This item appears only when you set the Phase Control item to [Manual Adjustment]. Conguration opti

3-12 Chapter 3: BIOS setupChapter 3DRAM Voltage [Auto]Allows you to set the DRAM voltage. The values range from 1.20V to 2.20V with a 0.00625V interva

ASUS P8P67 3-13Chapter 3Be cautious when changing the settings of the Advanced menu items. Incorrect eld values can cause the system to malfunction.3

viiiAbout this guideThis user guide contains the information you need when installing and conguring the motherboard.How this guide is organizedThis g

3-14 Chapter 3: BIOS setupChapter 33.5.1 CPU CongurationThe items in this menu show the CPU-related information that the BIOS automatically detects.

ASUS P8P67 3-15Chapter 3Hyper-threading [Enabled]The Intel Hyper-Threading Technology allows a hyper-threading processor to appear as two logical proc

3-16 Chapter 3: BIOS setupChapter 3CPU C6 Report [Enabled]Enables or disables the CPU C6 (ACPI C3) report to OS. Conguration options: [Disabled] [Ena

ASUS P8P67 3-17Chapter 33.5.4 SATA CongurationWhile entering Setup, the BIOS automatically detects the presence of SATA devices. The SATA Port items

3-18 Chapter 3: BIOS setupChapter 3S.M.A.R.T. Status Check [Enabled]S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) is a monitor syste

ASUS P8P67 3-19Chapter 33.5.6 Onboard Devices CongurationHD Audio Controller [Enabled][Enabled] Enables the High Denition Audio Controller.[Disabl

3-20 Chapter 3: BIOS setupChapter 3VIA 1394 [Enabled][Enabled] Enables the onboard IEEE 1394a controller.[Disabled] Disables the controller.PCI Expr

ASUS P8P67 3-21Chapter 3Restore AC Power Loss [Power Off][Power On] The system goes into on state after an AC power loss.[Power Off] The system goes

3-22 Chapter 3: BIOS setupChapter 3Power On By Ring [Disabled][Disabled] Disables Ring to generate a wake event.[Enabled] Enables Ring to generate

ASUS P8P67 3-23Chapter 33.6 Monitor menuThe Monitor menu displays the system temperature/power status, and allows you to change the fan settings.CPU

ixConventions used in this guideTo ensure that you perform certain tasks properly, take note of the following symbols used throughout this manual.Typo

3-24 Chapter 3: BIOS setupChapter 3CPU Q-Fan Control [Enabled][Disabled] Disables the CPU Q-Fan control feature.[Enabled] Enables the CPU Q-Fan cont

ASUS P8P67 3-25Chapter 3Chassis Fan Profile [Standard]This item appears only when you enable the Chassis Q-Fan Control feature and allows you to set t

3-26 Chapter 3: BIOS setupChapter 33.7 Boot menuThe Boot menu items allow you to change the system boot options.Bootup NumLock State [On][On] Sets t

ASUS P8P67 3-27Chapter 3Boot Option PrioritiesThese items specify the boot device priority sequence from the available devices. The number of device i

3-28 Chapter 3: BIOS setupChapter 33.8 Tools menuThe Tools menu items allow you to congure options for special functions. Select an item then press

ASUS P8P67 3-29Chapter 3• DO NOT shut down or reset the system while updating the BIOS to prevent the system boot failure!• We recommend that you up

3-30 Chapter 3: BIOS setupChapter 33.9 Exit menuThe Exit menu items allow you to load the optimal default values for the BIOS items, and save or disc

ASUS P8P67 3-31Chapter 33.10 Updating BIOSThe ASUS website publishes the latest BIOS versions to provide enhancements on system stability, compatibil

3-32 Chapter 3: BIOS setupChapter 3Updating the BIOS through the InternetTo update the BIOS through the Internet:1. From the ASUS Update screen, sele

ASUS P8P67 3-33Chapter 3• The screenshots in this section are for reference only. The actual BIOS information vary by models.• Refer to the software
